| Place of Origin: | CHINA |
| Brand Name: | ZHENGZHOU OCEAN |
| Certification: | ISO9001 Certificate |
| Model Number: | OEM |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden box |
| Delivery Time: | 8 months |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 10 sets/year |
| Usage: | Biodiesel Production Line For Sale | Installation And Training: | Free To Service It Overseas |
|---|---|---|---|
| Raw Material: | Vegetable Fat And Acid, Amimal Fat | Application: | Vehicles |
| High Light: | Biodiesel Production Line biodegradable OEM,Vehicle Fuel Biodiesel Production Line OEM,Renewable Biodiesel Production Line |
||
biodiesel Production Equipment New Technology Renewable Vehicle Fuel
General introduction of biodiesel Technology:
Two Main Section In Biodiesel Processing:
Biodiesel is mainly produced from animal and vegetable fats and oils, waste from vegetable oil refining and domestic waste oil, through complex esterification and methyl esterification reactions. Among them, the esterification reaction is the main part of biodiesel preparation. In this esterification process, the choice of catalyst and equipment is especially critical.
Our biodiesel esterification process and production equipment have the characteristics of short esterification time, high degree of esterification, low investment in production equipment, easy maintenance and low energy consumption.
In the process of biodiesel producing, the mixture of fatty acid methyl ester, glycerol and water with different carbon chain lengths is obtained after the esterification reaction, so it needs to be separated by the distillation section.
Our biodiesel esterification process and production equipment have the following characteristics:
(1)The distillation tower is connected with the esterification reactor, and the high concentration of methanol from the distillation is directly returned to the esterification reactor after condensation, which is conducive to improving the esterification reaction rate.
(2)Distillation directly removes the water generated after the reaction, effectively reducing the occurrence of esterification reverse reaction.
(3) By controlling the temperature and pressure, the fatty acid methyl ester mixture with different carbon chain length can be fractionated into fatty acid methyl ester with different carbon chain degree such as medium carbon chain fatty acid methyl ester and long carbon chain fatty acid methyl ester according to the customer's demand.
Biodiesel is a natural renewable, and alternative fuel for any diesel engine. it is a liquid fuel made from oil seeds crops such as soybean and rapeseed, oil seeds such as oil palm and yellow lily, oilseed aquatic plants such as engineered microalgae and animal fats and waste catering oil, which is a high quality substitute for petroleum diesel.
The CO2 emitted during the combustion of biodiesel is much lower than the CO2 absorbed by plants during their growth, thus ameliorating the major environmental problem of global warming, which is harmful to mankind, caused by CO2 emissions. Biodiesel is therefore a truly green diesel. The development of biodiesel is of strategic importance to the sustainable development of the economy, the promotion of energy substitution, the reduction of environmental pressure and the control of urban air pollution.
The EPA has recognized biodiesel's environmental benefits by classifying it as an Advanced Biofuel, making biodiesel the only commercial-scale fuel produced nationwide to meet the agency's advanced criteria.
Diesel molecule is composed of about 15 carbon chains, and the study found that vegetable oil molecules are generally composed of 14-18 carbon chains, which is similar to the number of oils
Therefore, biodiesel is a new type of fuel made from renewable vegetable oils such as rapeseed. According to the chemical composition analysis, biodiesel fuel is a high fatty acid methane, which is obtained by the decomposition of glycerolipids with unsaturated oleic acid carbon 18 as the main component.
Our patented biodiesel technology (Patent No. ZL 200620031879.7) is a fatty acid methyl ester liquid fuel that can replace diesel oil by using animal and vegetable fats and oils, waste from vegetable oil refining, and household waste oil as raw materials, and producing it through complex esterification and methyl esterification reactions.
ADVANTAGES:
CAPACITY : 3/5/10/20/30/50/100/200/300/500TPD
